Is this rattan? How much?

Raulin Arbor wrote:Is this rattan?

Yes.

Raulin Arbor wrote:How much?

The wood for the center one (15A) is $50 and can be found at http://stores.homestead.com/mga/-strse- ... Detail.bok
(the hardware is from Windrose).

[Edit: See below]. The fullers are more work.

The one on the left is 1 3/4" rattan planed to 1 1/4" and then beveled on the sides so that it retains a 3/4" wide strip of skin on the striking surface for most of its length. The strait fuller is 3/4" wide and runs from the base of the blade to a point 2" from the tip. The tip narrows to a 1 1/4" round circle. There is no linear taper, except at the tip and the entire piece of wood weighs in at a stout 1 lb 8.6 oz. The handle is both long and thick with an oval cross section and should probably be cut down for most hardware.

I call it a type 10. It is inspired by a Viking/early Norman blade.

The striking edge of the sword doesn't have to fall under the 1-1/4" thick rule?

Thanks!
Christopher

RenJunkie wrote:The striking edge of the sword doesn't have to fall under the 1-1/4" thick rule?

http://sca.org/officers/marshal/docs/marshal_handbook.pdf wrote:10. It shall not be possible to force any part of a weapon which may reasonably be expected to contact an opponent during combat more than 1/2 inch (12.7 mm) into a legal face guard. Rattan weapons may have a handle section which is less than 1 1/4 inch (31.8 mm), so long as it meets this criterion.

1. Single handed weapons shall be constructed of rattan or rattan-cored Siloflex or Siloflex equivalent and shall be not less than 1 1⁄4 inch (31.8 mm) in total diameter (including tape) along its entire length excepting the handle.

It is legal.

MacFin, could you post a bigger pic, or a link to a bigger one please?

Neat.

Soon I think I shall purchase one of these....

Thanks!
Christopher

The one on the right is 2" rattan with an even linear taper down to 1 1/4" at the tip. The edge is beveled on the sides so that it retains a 3/4" wide striking surface but without the skin, due to the taper. The triangular fuller is 3/4" wide at the base and ends at a point approx 2/3 of the way up the blade. The blade is six sided at the tip. The entire piece of wood weighs in at 1 lb 3.5 oz. The handle is both long and thick with an oval cross section and should probably be cut down for most hardware.

I call it a type 12 although it has characteristics of both an Oakshott Type XII and type XVI.

Vermillion wrote:MacFin, could you post a bigger pic, or a link to a bigger one please?

Not really. My photography stinks. I had to turn off the overhead light and the flash and put a lamp to the side to get the fullers to show up on film. In those conditions, the image is fuzzy at larger sizes. Here are a couple pics I shot of the tip of the type 10 with the flash on and off. Rattan reflects light well enough that they don't look like the same sword.



There are more pictures of the type 15A here:
http://forums.armourarchive.org/phpBB2/ ... p?t=119501

Golly gee! When the type 10s are ready for primetime, I may be needing me a couple or three

Eirik should have both of my new rattan waster prototypes and a few other styles at Midrealm's Crown Tourney at the end of the month.

Vermillion wrote:MacFin, could you post a bigger pic, or a link to a bigger one please?

Better? I delivered this batch to Baron Eirik today.

[url=http://www.flickr.com/photos/50288439@N03/5081077447/sizes/l/in/photostream/] http://www.flickr.com/photos/50288439@N ... otostream/

[/url]

Geez these are pretty!

$45 for the type 15 style short sword
$50 for the standard size type 15A (wood only: without the hardware in the top picture)
$75 for the type 10
$90 for the type 12

I forgot to ask Baron Eirik if he is charging $20 or $25 for the economy waster.

At this point he only has a few of any style waster. Email him if you want dibs.

By the way, in the latter picture, it looks like the tip of the type 10's are rounded. In reality, for those people that like thrusting tips, there is a flat 1 1/4" diameter disk on the end of each one.

Will these be posted to his site with measurements for each stick?

Thomas MacFinn wrote:I forgot to ask Baron Eirik if he is charging $20 or $25 for the economy waster.

$25. I wish I could cut more deals, but I have bills like everyone else.

Thank you Thomas for getting this info out, while not totally overwhelmed with a variety of Real Life(tm), it is keeping me from ever getting totally caught up.

Another batch headed toward Eirik for Midrealm's Crown Tourney and mail order:


http://www.flickr.com/photos/50288439@N03/5124237969/

GunnarUlfson wrote:Will these be posted to his site with measurements for each stick?

The site hasn't been updated in a while. Which measurements would you like? I'd be glad to post them here.

Finally getting some updates done!

Rattan Wasters Type 12 $90 (The one on the right in the pic)

[img]http://i673.photobucket.com/albums/vv92/mastereirik/MGA/Wasters_type12.jpg[/img]

Rattan Wasters Type 10 $75

[img]http://i673.photobucket.com/albums/vv92/mastereirik/MGA/Wasters_type10.jpg[/img]

Economy Rattan Wasters $25 (both of the daggers already sold, sorry)

[img]http://i673.photobucket.com/albums/vv92/mastereirik/MGA/econ_wasters.jpg[/img]

And the Rattan Wasters Type 15a are still $50

The site looks good. Thanks for posting the links with the pictures.

"One ping only, Vasili."

Now they're even back in the trailer where they belong.

While trying to get an order together, I'd had enough and finally finished reset the last of the post-Pennsic mess in the trailer.

Just a note on shaping rattan weapons.
All striking surfaces need to be "rounded".
Make sure that the weapon can not be put into an opening more than 1/2" and will pass the gauge for a width of 1.25" in any direction.

Be careful tapering the bevel of the blade or the weapon will go in more than 1/2"

I have bounced a few handmade ones in the past, none that came from Eirik though.
Just a friendly note.

There are usually a few corners that need a pass or two with some sandpaper when Thomas is done with them. But he is very careful on the measurements. But a friendly reminder is welcome.

Someone asked about lengths on the Economy Wasters and I can't find the post or PM it was in.

I have one at 41 inches overall length, 4 at 36" and one at 34". All over them have approximately 9 inches of handle.

The biggest SCA basket hilt I have seen (a plastic Baldar hilt) is 9 1/2" between the far ends of the tabs. Under the theory that it easier to cut than add rattan, most of the handles on my economy, type 10 and type 12 wasters are 9 1/2" long (the type 12 in the center of the picture below is an exception at 8"). Most of my type 15A's have a 12" tang.

On the economy wasters, that 9 1/2" is measured from the blade side of the black tape.


http://www.flickr.com/photos/50288439@N03/5124237969/
